CC175 - CC225 - CC275

Designed for hot countries according to European standards

The powerful CC175 and CC225 roof top units were specially designed for reliable climate comfort in midibuses whereas the additional model CC275 with 32kW is also suitable for larger vehicles. Ideal for either initial equipment or retrofitting, all models guarantee a cool interior at high outside temperature. High efficient radial blowers assure best air-flow and the units have a very small impact on fuel consumption due to low weight and high COP.

亮点

Product advantages

High cooling capacity
High air flow
Extreme low weight
Reduced refrigerant charge due to Multi-Flow-Condenser (MFC)technology

Benefits

Heating and fresh air optional
Easy installation
Easy maintenance access

技术数据

CC175 CC225 CC225W CC275 CC275W CC175W
Max. cooling capacity (kW) * 20 25 25 32 32
Airflow volume (m³/h) evaporator free blowing 4200 4200 4200 6300 6300
Max. outside temperature (°C) 55 55 55 55 55
Max. current consumption (12 V/ 24 V) 85A / 55A 92A / 64A 92A / 64A 88 A 88 A
Refrigerant (CFC-free) R 134a R 134a R 134a R 134a R 134a
Compressor (cm³) 210 310 310 400 - 560 400 - 560
Weight (kg) roof top unit 105 108 108 125 135
Dimension L x W x H (mm) 2.705 x 1.450 x 220 2.705 x 1.450x 220 2.750 x 1.715 x 220 3.105 x 1.450 x 220 3.105 x 1.715 x 220
* at outside temperature (°C) of coolant outlet (°C) of coolant flow (l/h)
W = wide, ** Heating is optional
